Z Shaped Steel Purlin Machine Process Flow:
Uncoiling→Feeding material into machine→Roll forming→Measuring length→ Auto cutting→Products receiving
Suitable Material Type:GI/PPGI/AL
Thickness:2.0-3.0mm
Length Tolerance:±2mm/6m
Working Speed:8-12m/min
Total Power:6KW
Total Weight:About 6.2T Up to final design
Components of Z Shaped Steel Purlin Machine:
Un-coiler System
Usage: It is used to support the steel coil and uncoil it in a turntable way.
Passive uncoil pulled by roll forming system
Usage: Put the raw material(steel plate) through the beach to manufacture and process,it can guarantee that the prodCoil feeding part of Z Shaped Steel Purlin Machine
ucts are neat, parallel and everything is uniformity.Please refer to the equipment regulation to know the function of locate angle iron.
Forming device of Z Shaped Steel Purlin Machine Usage: In order to keep the product shape and precision, adopts welded sheet structure, motor reducer drive, chain
transmission,roller was chromed which can keep the molding plate surface smooth and not easy to be marked when it is working
Feature : Ensure stability , precision and lifetime.
Length of the main part:6800*800*1200mm
Weight of main part:About 6.2 t
Voltage:380V/50HZ3Phase (as customer`s request)
Roller fixer:Guide column
Frame:Middle plate welded Memorial arch frame type
Frame thickness:25mm
Drive mode:Gear or chain
Material of rollers:45# steel with tempering
Material of shafts:45# steel with tempering
Diameter of shafts:φ80mm
Number of rollers:12rollers
Main power:11kw (Cycloidal planetary gear speed reducer)
